Вот такая надпись выскочила у меня в логе. Отсюда думаю и начались мытарства- показывает как через граненый стакан , не все имиджы пашут..
В инете не один раз встречается такая ошибка, но ответа нигде не увидел( у турок, немцев, чехов и китайцев) Прошу помочь знающих. Оговорюсь- перепрошивал всеми возможными способами и теперь сам готов консультировать по этому вопросу))). Все перепрошивания-Без изменений((. Поменял все емкости на блоке питания- без изменений. Давил и тискал процессор- без изменений( уточнение для Djazz)
Kernel command line: console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysar
ea=1280 coprocessor_mem=2m@0x04000000,2m@0x04200000
st-coprocessor: Failed to reserve memory at 0x04000000
st-coprocessor: Failed to reserve memory at 0x04200000
Полный лог
В инете не один раз встречается такая ошибка, но ответа нигде не увидел( у турок, немцев, чехов и китайцев) Прошу помочь знающих. Оговорюсь- перепрошивал всеми возможными способами и теперь сам готов консультировать по этому вопросу))). Все перепрошивания-Без изменений((. Поменял все емкости на блоке питания- без изменений. Давил и тискал процессор- без изменений( уточнение для Djazz)
Kernel command line: console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysar
ea=1280 coprocessor_mem=2m@0x04000000,2m@0x04200000
st-coprocessor: Failed to reserve memory at 0x04000000
st-coprocessor: Failed to reserve memory at 0x04200000
Полный лог
HTML:
Image Name: Linux-2.6.17.14_stm22_0037
Image Type: SuperH Linux Kernel Image (gzip compressed)
Data Size: 1740936 Bytes = 1.7 MB
Load Address: 84401000
Entry Point: 84402000
Verifying Checksum ... OK
Uncompressing Kernel Image ... OK
Starting kernel console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysarea=12
80 coprocessor_mem=2m@0x04000000,2m@0x04200000 - 0x00000000 - 0 ...
Linux version 2.6.17.14_stm22_0037 (klaus@obi-wan-kenobi) (gcc-Version 4.1.1 (ST
Microelectronics/Linux Base 4.1.1-23)) #1 PREEMPT Wed Jan 30 11:56:55 CET 2008
STMicroelectronics STb7100 Reference board initialisation
STb7100 version 3.x
Built 1 zonelists
Kernel command line: console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysar
ea=1280 coprocessor_mem=2m@0x04000000,2m@0x04200000
st-coprocessor: Failed to reserve memory at 0x04000000
st-coprocessor: Failed to reserve memory at 0x04200000
PID hash table entries: 256 (order: 8, 1024 bytes)
Using tmu for system timer
Dentry cache hash table entries: 8192 (order: 3, 32768 bytes)
Inode-cache hash table entries: 4096 (order: 2, 16384 bytes)
Memory: 31912k/40960k available (2901k kernel code, 9028k reserved, 364k data, 9
6k init)
PVR=04061100 CVR=30480000 PRR=00009100
I-cache : n_ways=2 n_sets=256 way_incr=8192
I-cache : entry_mask=0x00001fe0 alias_mask=0x00001000 n_aliases=2
D-cache : n_ways=2 n_sets=512 way_incr=16384
D-cache : entry_mask=0x00003fe0 alias_mask=0x00003000 n_aliases=4
Mount-cache hash table entries: 512
CPU: STb710x
NET: Registered protocol family 16
SCSI subsystem initialized
usbcore: registered new driver usbfs
usbcore: registered new driver hub
NET: Registered protocol family 2
IP route cache hash table entries: 512 (order: -1, 2048 bytes)
TCP established hash table entries: 2048 (order: 1, 8192 bytes)
TCP bind hash table entries: 1024 (order: 0, 4096 bytes)
TCP: Hash tables configured (established 2048 bind 1024)
TCP reno registered
bigphysarea: Allocated 1280 pages at 0x847c5000.
squashfs: version 3.0 (2006/03/15) Phillip Lougher
JFFS2 version 2.2. (NAND) (C) 2001-2003 Red Hat, Inc.
Initializing Cryptographic API
io scheduler noop registered
io scheduler anticipatory registered (default)
io scheduler deadline registered
io scheduler cfq registered
Device probe found data for platform device lirc
lirc_dev: IR Remote Control driver registered, at major 61
lirc_dev: lirc_register_plugin: sample_rate: 0
lirc_dev: lirc_register_plugin: plugin lirc_stm owner 00000000
STM LIRC plugin has IRQ 125
Lirc STM: Using IRB mode
STMicroelectronics LIRC driver configured
STPIO layer initialised
VFD_Controller Type : NEW Kathrein VFD
STMicroelectronics ASC driver initialized
ttyAS0 at MMIO 0xb8032000 (irq = 121) is a asc
ttyAS1 at MMIO 0xb8033000 (irq = 120) is a asc
RAMDISK driver initialized: 16 RAM disks of 4096K size 1024 blocksize
s_env_mac[0] = 0
s_env_mac[1] = 0
s_env_mac[2] = :
s_env_mac[3] = 1
s_env_mac[4] = d
s_env_mac[5] = :
s_env_mac[6] = e
s_env_mac[7] = c
s_env_mac[8] = :
s_env_mac[9] = 0
s_env_mac[10] = 0
s_env_mac[11] = :
s_env_mac[12] = 0
s_env_mac[13] = 0
s_env_mac[14] = :
s_env_mac[15] = 0
s_env_mac[16] = 0
get ether addr = 0, 1d, ec, 0, 0, 0
mac hi address = 0, lowaddress = ec1d00
SMSC: --> init_module()
SMSC: Driver Version = 1.21
SMSC: Compiled: Jan 30 2008, 11:55:58
SMSC: Platform: ST40 STMICRO r3
SMSC: Driver Parameters
SMSC: lan_base = 0x00000000, driver will decide
SMSC: bus_width = 0, driver will autodetect
SMSC: link_mode = 0x7F, 10HD,10FD,100HD,100FD,ASYMP,SYMP,ANEG
SMSC: irq = 2
SMSC: int_deas = 0xFFFFFFFF, use platform default
SMSC: irq_pol = 1, IRQ output is active high
SMSC: irq_type = 1, IRQ output is Push-Pull driver
SMSC: rx_dma = 256, RX will use PIO
SMSC: tx_dma = 256, TX will use PIO
SMSC: dma_threshold = 200
SMSC: mac_addr_hi16 = 0x00000000
SMSC: mac_addr_lo32 = 0x00EC1D00
SMSC: debug_mode = 0x00000007
SMSC: tx_fif_sz = 0x00050000
SMSC: afc_cfg = 0xFFFFFFFF, driver will decide
SMSC: tasklets = 0, Tasklets disabled
SMSC: phy_addr = 0xFFFFFFFF, Use internal phy
SMSC: max_throughput = 0xFFFFFFFF, Use platform default
SMSC: max_packet_count = 0xFFFFFFFF, Use platform default
SMSC: packet_cost = 0xFFFFFFFF, Use platform default
SMSC: burst_period = 0xFFFFFFFF, Use platform default
SMSC: max_work_load = 0xFFFFFFFF, Use platform default
SMSC: -->Smsc911x_init(dev=0x846F1A20)
SMSC: --> Platform_Initialize
SMSC: Lan Base at 0xA2000000
SMSC: <-- Platform_Initialize
SMSC: dwLanBase=0xA2000000
SMSC: LAN9115 identified, dwIdRev==0x01150002
SMSC: FPGA_REV == 0x00000000
SMSC: <--Smsc911x_init(), result=0
SMSC: Interface Name = "eth0"
SMSC: <-- init_module()
nwhw_config: device not found
ata1: SATA max UDMA/133 cmd 0xB9209000 ctl 0xB9209820 bmdma 0x0 irq 170
ata1: SATA link down (SStatus 0)
scsi0 : sata_stm
Generic ST boards onboard flash device: 0x01000000 (16.0Mb) at 0x00000000
Onboard_Flash: Found 1 x16 devices at 0x0 in 16-bit bank
Onboard_Flash: Found 1 x16 devices at 0x800000 in 16-bit bank
Amd/Fujitsu Extended Query Table at 0x0040
Onboard_Flash: CFI does not contain boot bank location. Assuming top.
number of CFI chips: 2
cfi_cmdset_0002: Disabling erase-suspend-program due to code brokenness.
Creating 9 MTD partitions on "Onboard_Flash":
0x00000000-0x00020000 : "Boot firmware : 0xA000.0000-0xA001.FFFF"
0x00040000-0x00200000 : "Kernel - 0xA004.0000-0xA01F.FFFF"
0x00200000-0x002a0000 : "Config FS - 0xA020.0000-0xA029.FFFF"
0x002a0000-0x004e0000 : "Root SQUASHFS- 0xA02A.0000-0xA04D.FFFF"
0x004e0000-0x00ae0000 : "APP_Modules 0xA04E.0000-0xA0AD.FFFF"
0x00ae0000-0x00c00000 : "EmergencyRoot 0xA0AE.0000-0xA0BF.FFFF"
0x00c00000-0x01000000 : "OtherData Var 0xA0C0.0000-0xA0FF.FFFF"
0x00020000-0x00040000 : "BootConfiguration 0xA002.0000-0xA003.FFFF"
0x00040000-0x01000000 : "Flash wo/ bootloader 0xA004.0000-0xA0FF.FFFF"
ST40_start_host_control
ST40_start_host_control proceeding
ST40-ehci ST40-ehci.2: ST EHCI Host Controller
ST40-ehci ST40-ehci.2: new USB bus registered, assigned bus number 1
ST40-ehci ST40-ehci.2: irq 169, io mem 0xb91ffe00
ST40-ehci ST40-ehci.2: USB 0.0 started, EHCI 1.00, driver 10 Dec 2004
usb usb1: Product: ST EHCI Host Controller
usb usb1: Manufacturer: Linux 2.6.17.14_stm22_0037 ehci_hcd
usb usb1: SerialNumber: STB7100_EHCI
usb usb1: configuration #1 chosen from 1 choice
hub 1-0:1.0: USB hub found
hub 1-0:1.0: 1 port detected
Initializing USB Mass Storage driver...
usb 1-1: new high speed USB device using ST40-ehci and address 2
usb 1-1: Product: USB2.0 Hub
usb 1-1: configuration #1 chosen from 1 choice
hub 1-1:1.0: USB hub found
hub 1-1:1.0: 4 ports detected
usb 1-1.4: new high speed USB device using ST40-ehci and address 3
usb 1-1.4: Product: Mass Storage Device
usb 1-1.4: Manufacturer: Generic
usb 1-1.4: SerialNumber: D8CARNOA
usb 1-1.4: configuration #1 chosen from 1 choice
scsi1 : SCSI emulation for USB Mass Storage devices
usbcore: registered new driver usb-storage
USB Mass Storage support registered.
usbcore: registered new driver libusual
pegasus: v0.6.13 (2005/11/13), Pegasus/Pegasus II USB Ethernet driver
usbcore: registered new driver pegasus
usbcore: registered new driver asix
usbcore: registered new driver cdc_ether
usbcore: registered new driver net1080
usbcore: registered new driver zaurus
mice: PS/2 mouse device common for all mice
i2c /dev entries driver
stssc layer initialized
STMicroelectronics - Coprocessors st231 Init
st231-0 Coprocessor -------------------------------------------
flags 0001 RAM start at 0xa4000000 size 0x00200000
cop. addr 0x04000000
Channels : Not defined
IRQ : not used
---------------------------------------------------------------
st231-1 Coprocessor -------------------------------------------
flags 0001 RAM start at 0xa4200000 size 0x00200000
cop. addr 0x04200000
Channels : Not defined
IRQ : not used
---------------------------------------------------------------
TCP bic registered
TCP highspeed registered
NET: Registered protocol family 1
NET: Registered protocol family 17
SMSC: -->Smsc911x_open(dev=0x846F1A20)
SMSC: -->Lan_Initialize(dwIntCfg=0x00000011)
SMSC: <--g_GpioSetting set
SMSC: <--Lan_Initialize
SMSC: Testing ISR using IRQ 2
SMSC: ISR passed test using IRQ 2
SMSC: Mac Address is set by parameter to 0x000000EC1D00
SMSC: -->Phy_Initialize
SMSC: dwPhyId==0x00C0001C,bPhyModel==0x0D,bPhyRev==0x01
SMSC: Successfully Verified Loop Back Packet
SMSC: Passed Loop Back Test
SMSC: <--Phy_Initialize, result=TRUE
SMSC: Tx will use PIO
SMSC: Rx will use PIO
SMSC_WARNING: Gpt_CancelCallBack: Failed
SMSC: <--Smsc911x_open, result=0
SMSC_WARNING: Gpt_CancelCallBack: Failed
IP-Config: Incomplete network configuration information.
SMSC: -->Smsc911x_stop(dev=0x846F1A20)
SMSC: <--Smsc911x_stop, result=0
VFS: Mounted root (cramfs filesystem) readonly.
Freeing unused kernel memory: 96k freed
init started: BusyBox v1.2.1 (2007.10.12-18:30+0000) multi-call binary
/etc/init.d/rcS started...
Bringing up the loopback interface...
Setting up hostname...
eth0: 192.168.0.25/255.255.255.0 gw 192.168.0.1 dns 192.168.0.1
SMSC: -->Smsc911x_open(dev=0x846F1A20)
SMSC: -->Lan_Initialize(dwIntCfg=0x00000011)
SMSC: <--g_GpioSetting set
SMSC: <--Lan_Initialize
SMSC: Testing ISR using IRQ 2
SMSC: ISR passed test using IRQ 2
SMSC: Mac Address is set by parameter to 0x000000EC1D00
SMSC: -->Phy_Initialize
SMSC: dwPhyId==0x00C0001C,bPhyModel==0x0D,bPhyRev==0x01
SMSC: Successfully Verified Loop Back Packet
SMSC: Passed Loop Back Test
SMSC: <--Phy_Initialize, result=TRUE
SMSC: Tx will use PIO
SMSC: Rx will use PIO
SMSC_WARNING: Gpt_CancelCallBack: Failed
SMSC: <--Smsc911x_open, result=0
SMSC: Multicast: enable dwBitNum=31,addr=01 00 5E 00 00 01
SMSC_WARNING: Gpt_CancelCallBack: Failed
SMSC: Multicast: enable dwBitNum=31,addr=01 00 5E 00 00 01
/config/start.sh exists .... running /config/start.sh
Please press Enter to activate this console. SMSC_WARNING: Gpt_CancelCallBack: F
ailed
Vendor: JetFlash Model: TS512MJFV30 Rev: 8.07
Type: Direct-Access ANSI SCSI revision: 02
SCSI device sda: 991232 512-byte hdwr sectors (508 MB)
sda: Write Protect is off
sda: assuming drive cache: write through
SCSI device sda: 991232 512-byte hdwr sectors (508 MB)
sda: Write Protect is off
sda: assuming drive cache: write through
sda: sda1
sd 1:0:0:0: Attached scsi removable disk sda
SMSC: Link is now UP at 100Mbps FD
SMSC: LAN911x: ASYMP,SYMP ,100FD,100HD,10FD ,10HD
SMSC: Partner: , ,100FD,100HD,10FD ,10HD
PARAM : boot_param_version=8
PARAM : board=stb7100ref_27
PARAM : bootcmd=bootm a0040000
PARAM : bootdelay=1
PARAM : ethaddr=00:1d:ec:00:00:00
PARAM : bootargs=console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysarea=1
280 coprocessor_mem=2m@0x04000000,2m@0x04200000
PARAM : stdin=serial
PARAM : stdout=serial
PARAM : stderr=serial
PARAM : autoload=n
BOOT PARAM VERSION = 8
mount: Mounting none on /proc/bus/usb/ failed: Device or resource busy
mkdir: Cannot create directory `/tmp/usb': File exists
/config/start.sh: /config/start.sh: 11: cannot open /data/.crontab: No such file
/config/start.sh: /app/modules_sys/bin/stapi_modlist_mknod.sh: 14: /app/modules_
sys: Permission denied
MODULE_INSTALL_DIR = /app/modules_sys/modules26
BIN_INSTALL_DIR = /app/modules_sys/bin
##########################################################
the reference tree was released on W650
##########################################################
stos_core: module license 'ST Microelectronics' taints kernel.
stos_core_init_module(): Initializing STOS Module
stcommon_core_init_module(): Initializing STCOMMON Module
Setting all Group priorities done
PTI Clock: Cut 3.0 detected -> setting PTI workaround clock.
TC_Ram test...
Writing...
Reading...
ok
Preproc Clock: Cut 3.0 detected -> setting Preproc clock.
stpio_core_init_module(): Initializing STPIO Module
Load module fdma [254] by insmod (pid 375)
STFDMA_ClbckMgr: task created ... Priority=99
Load module stpti4_core by insmod (pid 378)
Load module stclkrv_core by insmod (pid 380)
hdmi_i2c_init : Initializing I2CHDMI kernel Module
the adapter name is i2c-ssc-0 number 0
the adapter name is i2c-ssc-1 number 1
the adapter name is i2c-ssc-2 number 2
mod_lxload_init: Initializing LXLOAD kernel Module, StartAddress: 0x04200000
Load module lxload[253] by insmod (pid 401)
LXLOADER virtual io kernel address of phys 0xa4200000 = 0xa4200000
/dev/stapi/lxload
mknod -m 0660 /dev/stapi/lxload c 253 0
loading audio binlxload_open: major=253 minor=0
setting up Audio LX in NON-DEBUG mode
ary file
lxload_release: major=253 minor=0
Starting Audio LX by disabling reset
LX loaded:
Base: 0xa4200000
Last: 0xa4347284
Size:1340036
mod_lxload_exit: Exiting LXLOAD kernel Module
The I/O memory region 0x04200000 is released successfully
Unload module lxload by rmmod (pid 410)
mod_lxload_init: Initializing LXLOAD kernel Module, StartAddress: 0x04000000
Load module lxload[253] by insmod (pid 412)
LXLOADER virtual io kernel address of phys 0xa4000000 = 0xa4000000
/dev/stapi/lxload
mknod -m 0660 /dev/stapi/lxload c 253 0
lxload_open: major=253 minor=0
setting up LX in NON-DEBUG mode
lxload_release: major=253 minor=0
Starting video LX by disabling reset
LX loaded:
Base: 0xa4000000
Last: 0xa403403c
Size:213052
mod_lxload_exit: Exiting LXLOAD kernel Module
The I/O memory region 0x04000000 is released successfully
Unload module lxload by rmmod (pid 421)
EMBXSHM-PortClosed: with RT priority done with syscall. PID=434
EMBX EMBXSHM-PortClosed: task created ...
EMBXSHM-NewPort: with RT priority done with syscall. PID=433
EMBX EMBXSHM-NewPort: task created ...
mknod -m 0660 /dev/stapi/sti2c_ioctl c 253 0
Load module staudlx_core [252] by insmod (pid 447)
sthdmi_ioctl_init_module: Initializing STHDMI IOCTL Module
Load module sthdmi_ioctl[251] by insmod (pid 451)
mknod -m 0660 /dev/stapi/sthdmi_ioctl c 251 0
Load module stvid_ioctl[250] by insmod (pid 459)
mknod -m 0660 /dev/stapi/stvid_ioctl c 250 0
Load module stevt_ioctl [249] by insmod (pid 467)
mknod -m 0660 /dev/stapi/stevt_ioctl c 249 0
stblit_ioctl_init_module: Initializing STBLIT IOCTL Module
Load module stblit_ioctl[248] by insmod (pid 475)
mknod -m 0660 /dev/stapi/stblit_ioctl c 248 0
stlayer_ioctl_init_module: Initializing STLAYER kernel Module
Load module stlayer_ioctl[247] by insmod (pid 483)
mknod -m 0660 /dev/stapi/stlayer_ioctl c 247 0
Load module stpti4_ioctl [246] by insmod (pid 491)
mknod -m 0660 /dev/stapi/stpti4_ioctl c 246 0
Load module stclkrv_ioctl [245] by insmod (pid 499)
mknod -m 0660 /dev/stapi/stclkrv_ioctl c 245 0
stdenc_ioctl_init_module: Initializing STDENC IOCTL Module
Load module stdenc_ioctl[244] by insmod (pid 507)
mknod -m 0660 /dev/stapi/stdenc_ioctl c 244 0
stvtg_ioctl_init_module: Initializing STVTG IOCTL Module
Load module stvtg_ioctl[243] by insmod (pid 515)
mknod -m 0660 /dev/stapi/stvtg_ioctl c 243 0
stvout_ioctl_init_module: Initializing STVOUT IOCTL Module
Load module stvout_ioctl[242] by insmod (pid 523)
mknod -m 0660 /dev/stapi/stvout_ioctl c 242 0
stvmix_ioctl_init_module: Initializing STVMIX IOCTL Module
Load module stvmix_ioctl[241] by insmod (pid 531)
mknod -m 0660 /dev/stapi/stvmix_ioctl c 241 0
stvbi_ioctl_init_module: Initializing STVBI kernel Module
Load module stvbi_ioctl[240] by insmod (pid 539)
mknod -m 0660 /dev/stapi/stvbi_ioctl c 240 0
Load module stmerge_ioctl [239] by insmod (pid 547)
mknod -m 0660 /dev/stapi/stmerge_ioctl c 239 0
Load module staudlx_ioctl[238] by insmod (pid 555)
mknod -m 0660 /dev/stapi/staudlx_ioctl c 238 0
utils_ioctl_init_module: Initializing UTILS IOCTL Module
Load module utils_ioctl[237] by insmod (pid 563)
mknod -m 0660 /dev/stapi/utils_ioctl c 237 0
Load module stinj_ioctl [236] by insmod (pid 571)
mknod -m 0660 /dev/stapi/stinj_ioctl c 236 0
Load module stpio_ioctl [235] by insmod (pid 579)
mknod -m 0660 /dev/stapi/stpio_ioctl c 235 0
Unload module stttx_core by insmod (pid 589)
CIMAX DeviceInit
SysConf device Init
LMI_SYS VCR0 = 00d40000
LMI_SYS VCR1 = 0f041000
LMI_SYS MIM0 = 861a0247
LMI_SYS MIM1 = 01010022
LMI_SYS SCR = 00000000
LMI_SYS STR = 35b06455
LMI_SYS COC = 00000000
LMI_SYS SDRA0 = 08001900
LMI_SYS SDRA1 = 08001900
LMI_SYS CIC = 00000249
LMI_SYS SDMR0 = 00000000
LMI_SYS SDMR1 = 00000000
LMI_VID VCR0 = 00d40000
LMI_VID VCR1 = 17101000
LMI_VID MIM0 = 861a0247
LMI_VID MIM1 = 01010022
LMI_VID SCR = 00000000
LMI_VID STR = 35b06455
LMI_VID COC = 00000000
LMI_VID SDRA0 = 14001900
LMI_VID SDRA1 = 14001900
LMI_VID CIC = 00000249
LMI_VID SDMR0 = 00000000
LMI_VID SDMR1 = 00000000
UFS910 Button Device Driver(by Marusys Co.)
insmod: /lib/modules/2.6.17.14_stm22_0037: No such file or directory
insmod: cifs.ko: no module by that name found
TestModMgr::CheckTestMode CmdLine = console=ttyAS0,115200 root=/dev/mtdblock3 me
m=40m bigphysarea=1280 coprocessor_mem=2m@0x04000000,2m@0x04200000
CMDLINE = console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysarea=1280 cop
rocessor_mem=2m@0x04000000,2m@0x04200000
CMDLINE = console=ttyAS0,115200 root=/dev/mtdblock3 mem=40m bigphysarea=1280 cop
rocessor_mem=2m@0x04000000,2m@0x04200000
cannot fine test mode
TestModeMgr::CheckMode : TestMode Disabled
Последнее редактирование:
